Product Introduction
A versatile stereo reverb pedal with eight algorithms ranging from cathedral to experimental wave modulation. Features adjustable sample rate (20,000–48,000 Hz) that lets you slow down or speed up reverb tails as if changing room dimensions. Sustain button creates long synth-like pads. True bypass and buffered bypass modes with trail support.
Product Features
🎛️ 8 Reverb Algorithms
Cathedral, Blackhole, Plate, Shimmer (octave up), Octo (octave down), Spring, Hall, and Wave (heavy modulation). Each algorithm has unique control mappings for pre-delay, octave level, modulation depth, and tone shaping.
⏱️ Adjustable Sample Rate (20kHz–48kHz)
The “Time” knob lets you dial the internal clock speed from 20,000 to 48,000 samples per second. Slow it down for cavernous, elongated tails. Speed it up for tighter, brighter room sounds — like changing the physical size of your reverb space.
🎹 Sustain Button with Latching Mode
Hold the Sustain button to max out decay time and create infinite, synth-like reverb pads under your playing. Latching switch lets you lock it on hands‑free or use momentary mode.
🔊 Separate Dry & Wet Volume Controls
Independent knobs for clean (dry) signal and reverb (wet) volume. Studio-style dry/wet mixing eliminates volume jumps when engaging or bypassing the pedal.
🔄 Dual Bypass Modes – Trails Optional
Buffered bypass (default) allows reverb tails to fade naturally after switching off. True relay bypass fully removes the pedal from your signal path. Programmable via hold-to-select interface.
🔌 Stereo Input/Output (TRS Compatible)
Clean signal path is fully analog and stereo. Reverb engine sums inputs to mono, processes, then outputs true stereo — like miking a room with two microphones. Works with mono TS or stereo TRS cables.
⚡ 18V Internal Conversion from 9V Power
Runs on standard 9V DC (150mA, center negative). Internal circuitry converts to 18V for improved headroom and lower noise. Overvoltage and reverse polarity protection included.
Product Specifications
- Product Name: Stereo Reverb Pedal
- Algorithms: 8 (Cathedral, Blackhole, Plate, Shimmer, Octo, Spring, Hall, Wave)
- Sample Rate Range: 20,000 – 48,000 Hz (adjustable)
- Bypass Modes: Buffered (trails) / True relay bypass (programmable)
- Sustain: Momentary or latching with max decay
- Controls: Dry volume, wet volume, time (sample rate), pre‑delay/mod/octave (varies by algorithm), tone/mod frequency, decay
- Connections: 2x 6.35mm inputs (L/R), 2x outputs (L/R) – TS or TRS compatible
- Power: 9V DC (150mA, center negative) – internal 18V conversion
- Dimensions: 94 × 124 × 55 mm
- Weight: ~420 g
Packaging Includes
- 1 × Stereo Reverb Pedal
- 1 × User Manual (Russian/English)
✨ Eight worlds of reverb, infinite sustain, and time you can twist — all in one stereo pedal.
